Nextivity CEL-FI QUATRA EVO

QUATRA EVO is an Active DAS Hybrid that is equipped with the latest 4th generation Nextivity proprietary IntelliBoost chip to ensure uniform, high-quality cellular signal throughout any building.

Categories: ,

Description

Solving cellular coverage challenges for enterprise environments, Nextivity CEL-FI QUATRA EVO is an active DAS hybrid that offers uniform, high-quality cellular signal throughout any building. As an all-digital solution, QUATRA EVO utilizes category cabling for RF and Power-over-Ethernet architecture to deliver industry-leading signal gain and scalability. In addition to unmatched performance, this cost-effective, carrier-grade system offers fiber expansion capabilities to scale up your coverage area and can be installed within days.

Key Features

  • Scalable all-digital active DAS hybrid for enterprise environments
  • Flexible to configure for single or dual operator server application
  • Multi-carrier signal booster for 3G, 4G, and 5G with industry-leading signal gain up to 100 dB
  • Carrier approved and unconditionally network safe
  • Lossless RF signal and Power-over-Ethernet (PoE) distribution with easy-to-install category cable architecture
  • Site installation flexibility with operator specific donor antenna or small cell signal source
  • Remotely monitor and configure with Nextivity WAVE Portal cloud management

Specifications

Network Selection

Automatically best available (WAVE Portal for manual setting)

Duplex Modes

FDD & TDD

# of Relay Bands

4 max

Independent Operators Supported

2 max

Relay Bandwidth per NU Donor Port A or B

20 + 20 MHz max

System Gain

100 dB max

Enterprise-Grade Echo Cancellation

30 dB min.

Noise Figure (All Bands)

7 dB max. at ambient

Return Loss

-8 dB max

UL Transmit EVM

8.5 %, 16-QAM with full RB allocation

DL Transmit EVM

8.5%, E-TM3.1

DL Input Level

-100 to -40 dBm

RF Interface Impedance (All Ports)

50 Ω

NU to CU Cable

2x Category Cables ANSI/TIA/EIA 568-B Compliant

NU to CU Cable Distance

328 ft (100 m) (656 ft (200 m) with Nextivity CEL-FI QUATRA Range Extender) max

Product Settings & SW Updates

WAVE Portal for Desktop
